Technical Specification
Type: Horizontal Type (Rectangular) |
Outer Body & Inner Chamber : Stainless steel 304/316 Grade |
Insulation: 75 mm Glass Wool Insulation |
LID: Made of Thick Stainless steel |
Locking System: Screw Type Locking |
Gasket: Nepolene |
Working Pressure: 15 to 22 PSI |
Working Temperature: 121 °C to 132 °C |
Base Stand: SS or MS |
Pressure Control device: PIEZOSTAT |
Power Requirement: 220/240 VAC Single/Three Phases |
Capacity (Liter): 100, 180, 240, 320, 430, 540, 810 |
OPTIONAL ACCESSORIES: Digital Temperature Indicator, Digital Temperature Indicator + Digital Timer, Double Door System, Automatic controlling System, Fully Automatic Touch Screen & PLC Based Controller. |
