Technical Specification
| Outer body: Outer made of M.S. sheet duly enamel painted. |
| Inner body: Inner made up of heavy gauge S.S. sheet. |
| Temperature range: 50°C to 150°C . |
| Vacuum range: 10 to 750 mm Hg. |
| Door Gasket: High Temperature Silicon Rubber. |
| Material Insulation: Mineral Wool. |
| Display: Digital LED display for SV and PV. |
| Controller: Microprocessor Based Digital Temperature Indicator Cum Controller. |
| Accuracy: ± 3°C. |
| Sensor: Pt -100. |
| Power supply: 220/230V, 50/60Hz. |
| Heat load: 1.5 K.W, 2.50 K.W. Chamber size(mm): 250 X 250, 250 X 300, 300 X 300, 300 X 375. |
| OPTIONAL ACCESSORIES: Vacuum Pump. |
