Technical Specification
| Measuring Range: 0.000 to 3.500 Absorbance units (A) |
| Photometric Accuracy: ± 2% or 0.007 |
| Type of Filter: High quality narrow band interference |
| Optical Measurement; 8 Channel |
| Display: 6 Inches Graphics LCD |
| Human Machine Interface: Touch Panel Keypad |
| Wave Length: 405nm, 450nm, 492nm, 630nm, 560nm & Three position for optional filter |
| Selection of filter: Automatic by stepper motor |
| Curve Plotting: Graphical representation on printer |
| Half Bandwidth: 10nm ± 2nm |
| Memory: 250 tests and more than 2500 results |
| Analysis Mode: Absorbance, Cut-off, Multi-Standard, % Absorbance, Single Standard, Uptake, Kinetic |
| RS232: Serial Port/USB 9600 baud, 8 data, 1 stop, no parity bits/ USB Power: 75 Watts / 115 - 230 Volts ± 10%, 50 / 60 Hz |
